Fitted with stopping ring, this protects the cylinder when the piston comes to a stop because it absorbs the weight from the other side Spring loaded piston which allows for quick release Fitted with O-ring for outstanding seal performance and a long service life
Tonnage Capacity: 30 Tonne Stroke: 100mm Min. Oil Required: 471cm³ Closed Height: 187mm Extended Height: 287mm Outside Diameter: 103mm Inside Diameter: 75mm Piston Rod Diameter: 65mm Net Weight: 10.7kg
Individual Product Details
Height: 200mm - Width: 200mm - Length: 150mm - Weight: 11kg
