Fitted with stopping ring, this protects the cylinder when the piston comes to a stop because it absorbs the weight from the other side Spring loaded piston which allows for quick release Chrome plated cylinder wall and primary piston to prevent corrosion and reduce friction Tundra® Hydraulic Cylinders provide a reliable device for safely lifting large structures
Tonnage Capacity: 50 Tonne Stroke: 16mm Min. Oil Required: 101cm³ Closed Height: 72mm Extended Height: 88mm Length x Width: 148mm x 120mm Inside Diameter: 95mm Piston Rod Diameter: 70mm Net Weight: 7.8kg
Individual Product Details
Height: 140mm - Width: 210mm - Length: 80mm - Weight: 8kg
