Fitted with stopping ring, this protects the cylinder when the piston comes to a stop because it absorbs the weight from the other side Spring loaded piston which allows for quick release Fitted with O-ring for outstanding seal performance and a long service life
Tonnage Capacity: 100 Tonne Stroke: 100mm Min. Oil Required: 1530cm³ Closed Height: 232mm Extended Height: 332mm Outside Diameter: 168mm Inside Diameter: 135mm Piston Rod Diameter: 90mm Net Weight: 30.6kg
Individual Product Details
Height: 191mm - Width: 145mm - Length: 255mm - Weight: 13.6kg
