This magnetic drill is designed for drilling holes in steel fabrication work It is an ideal portable drilling solution equally suited for use in building sites or the workshop environment and can be used to cut in horizontal, vertical and overhead positions. The magnetic drill uses an annular hole cutter (sometimes called a slugger bit) to cut clean and accurate holes without pre-drilling or step drilling After cutting through the steel the cutter produces a "slug" (a cylindrical lump of steel) that falls from the centre of the cut 2 speed mechanical gearbox Supplied with metal case
Maximum Cutting Capacity: 65mm Maximum Tapping Diameter: M20mm Maximum Twist Drill Diameter: 25mm Maximum Cutting Depth: 50mm Input Voltage: 110V Magnetic Adhesion: 15,800N Motor Power / Speed: 1890W No Load Speed: 100-180/500rpm Dimensions: 390 x 110 x 390mm Weight: 28kg
Outer Packaging Details
Height: 490mm - Width: 240mm - Length: 560mm - Box Qty: 1mm - Weight: 35kg
Individual Product Details
Height: 390mm - Width: 110mm - Length: 390mm - Weight: 23kg
